Product Description
A high-temperature pump specifically designed for hot water and thermal oil applications up to 180°C. Built with stainless steel (SS304) body, copper impeller, and ceramic shaft for durability and resistance to thermal stress. Suitable for industrial heating and circulation systems.
Detailed Technical Specifications
|
Parameter |
Unit |
2051-MK (50Hz) |
|
Speed |
rpm |
2800 |
|
Flow Rate |
L/min |
63 |
|
Motor Power Options |
kW |
0.25 / 0.37 / 0.5 |
|
Corresponding Max. Head |
m |
20 / 35 / 45 |
|
Max. Lift |
m |
1.5 / 1.8 / 2.1 |
|
Connection Size |
inch |
GS: 1/2, GD: 1/2 (or SAE 3/4) |
|
Max. Temp. |
°C |
Water: 140 | Oil: 180 |
Material Specifications & Guidelines
* Materials: Body: SS304 | Impeller: Stainless Steel, Copper | Shaft: Ceramic with PEEK.
* Application: Ideal for closed-loop heating systems. Pre-heating recommended for * * high-temp startup. Use with appropriate viscosity thermal oils.
